Pedalboard / 124
Dann Huff
A deliberately compact working board combines three gain voices, chorus and vibrato, modulated reverb, analogue-style delay and an M9 utility processor.
Signal path / A
Home-studio working board
Visual rig rundown · inventory verified, routing reconstructed
Reconstructed equipment · Reconstructed order · Serial path
Premier Guitar's long-form video and accompanying article visually verify every device in this snapshot, with the pedalboard segment beginning at 1:33:40. Neither the article nor the accessible chapter map traces the cables, so the displayed progression follows the rundown inventory and conventional functional grouping; it is not presented as a verified serial order. Vertex's builder-authored 2012 map independently establishes Huff's earlier board and demonstrates why the two eras must remain separate, but it is not used to infer the 2025 wiring.
